This 200W solar panel kit has been designed for easy setup and battery connection.
The panels have a strong 30mm anodised aluminium frame, toughened glass and are connected to each other by hinges.
They also have a lightweight strong aluminium swing down leg system.
Protective plastic corners are installed to each of solar panels.
Unfolding the kit is done by removing it from the protective bag, opening the latches that keep the kit closed, swing the support legs down from the back of the panels.
Included is a regulator that is installed on a bracket which swings down from the panel frame to make viewing of the information on the regulator’s LCD screen much easier.
The regulator can charge Sealed Lead Acid, Gel, Flooded Lead Acid, Ternary Lithium or Lithium Iron Phosphate Batteries.
Connection to the battery can be done using the Anderson style plug or battery clips which are installed on the long lead.
The regulator is wired with Anderson style plugs so it can be bypassed to make the kit usable with other dc to dc chargers with an inbuilt solar regulator.
|Maximum power (Pmax)
|Maximum power voltage (Vmp)
|Maximum power current (Imp)
|Open circuit voltage (Voc)
|Short circuit voltage (Isc)
|Maximum system voltage
|770 x 670 x 65mm
|Solar Controller / Regulator
