This controller is suitable for all kinds of Lead Acid Batteries (including Sealed, Flooded, AGM, Gel), Lithium Ion Batteries and Lithium Iron Phosphate Batteries.
Features:
- Built-in industrial micro controller
- IR remote control
- Auto memory function
- IP68 protection
- 4-stage PWM charge management
- Built-in short circuit protection, open circuit protection, reverse protection and overload protection
SPECIFICATIONS
| Model | IR-B |
| Size | 82 x 58 x 21mm |
| Installing hole size | 74.5 x 44.4mm |
| Weight | 135g |
| Remote function | Yes |
| Battery voltage | 12V/24V auto adapt |
| Max solar input | 50V |
| Self-consume | <10mA |
| Voltage of open light | Solar panel 8V (delay 10s) |
| Voltage of close light | Solar panel 8V (delay 60s) |
| Operating temperature | -20°C to +60°C |
| Battery type | Lead acid | Lithium ion | LiFePO4 |
| Equalization | 14.4V | ||
| ABS | 14.2V | ||
| Float | 13.8V | 12.6V | 14.4V |
| Discharge stop | 11.2V | 9V | 10V |
| Discharge reconnect | 12.6V | 10.5V | 12V |
*all red colour voltage ×2 while using 24V system
