- Adopt MPPT with tracking efficiency up to 99.9%
- Support full-power charging and discharging at one time
- Support multiple battery types such as sealed battery, gel battery, flooded battery, lithium battery and user-defined battery
- 17 load operating modes
- Save historical data for 200 consecutive days
TECHNICAL PARAMETERS
Static power consumption | ā¤10mA |
Battery Type | SLD/GEL/FLD/LI/USE/USELI, SLD as default |
System voltage | 12V/24V |
Battery operating voltage range | 8V-32V |
MPPT tracking efficiency | >99% |
Charging conversion efficiency | 85%-98% (10%-100% of rated power) |
Rated load current | 20A |
Load operating mode | Light control, light control + time control, manual mode (default), debugging mode, normally open |
Protection function | PV overvoltage protection, PV reverse connection protection, PV short circuit protection, night reverse charging protection, input power limit protection, over-temperature protection, load short-circuit protection, overload protection, battery over-voltage/over-discharge protection, battery reverse connection protection, battery end short circuit protection. |
Grounding type | Grounding of common negative electrode |
Operating ambient temperature range | -35ā~65ā |
Protection grade | IP32 |
Cooling mode | Natural heat dissipation |
